Digital Video Doorphone System
Video Doorphone System
After years of development, series 755 is now introduced as a smarter, more efficient apartment monitoring system utilizing the latest CPU controlled technology. System comes in two versions -
The MK-755 Security Alarm audio & video intercom system or the PH-755 audio & video version.
  • Manual or remote arm-disarm of security alarm system
  • 3 supervised zones (1 24hr zone for gas / fire detect and panic, 2 zones for anti-burglar zones) in system; the 1st anti-burglar zone can be made a delayed set and a switch for starting the system.
  • Self diagnose feature allows system checking every 10 seconds (Security system only)
  • Easy installation since programming of system can be done in the workshop before going to site
  • Guard controller memory for the last 10 calls from any residence
  • Easy wiring and after sales servicing and maintenance
  • Security and fire section offers 2 anti-burglar zones & 1 24hrs zone for security, fire & panic devices
  • Programming of residence numbers via hand held programmer
  • Full monitoring by guard controller via LED indicator
  • Hard copy printout of the last 8 events and visual memory status for the last 1,500 events via scrolling
  • "Real Time" hard copy event printout
  • LED indicator on residence monitor if a call from guard controller was made but not answered
  • System was designed with reliability and easy usage in mind
755C2 VCP (Colour or B/W CCD )
755PU (Processor Unit)
  • Password door open function available
  • Power In: DC15V by adaptor
  • Resolution: Colour-480 TV line
    B/W-500 TV line
  • Lens: Auto
  • CCD: 1/3" Colour or [B/W] CCD
  • F1.8,Full angle 92 degrees
  • Min. illumination: Colour-0.1 Lux
    B/W-0.1 Lux (w 12 pcs LED)]
  • Dimension: 300/200/75mm
  • Packing: 0.25 cubic ft
  • Weight: 2.7 kg
  • Need Prebox
  • Power In: AC100/110/120/220/230V
  • Dimension: 200W/300H/420D mm
  • Packing: 1.30 cubic ft
  • Weight: 6.0 kg
755SC (The Control Console)
755CC (The Control Centre)
  • Power In: Supply from 755PU
  • Decode: 10 call memory for 755CC
  • Review: Checking the last 10 call memory
  • Two Types: 5 Blocks / 10 Blocks
  • Dimension: 305/210/60 mm
  • Packing: 0.7 cubic ft
  • Weight: 3.0 kgs
This is the bridge between the Resident and VCP, pls refer to our Instruction Guide for the other functions.
  • Power In: Supply from 755PU
  • Decode: 10 call memory for 755CC
  • Review: Checking the last 10 call memory
  • Two Types: 5 Blocks
  • Dimension: 305/210/60 mm
  • Packing: 0.7 cubic ft
  • Weight: 3.0 kgs
MK755M or M+ (The Alarm Monitor)
755C3/C3X with/without CCD
  • Power In: DC15V ~18V
  • Screen: Colour- 4" Colour TFT LCD [B/W- 4" Flat CRT]
  • Resolution: Colour-105,196 pixels/ 442H X 238V [B/W-500 TV line]
  • Calling tone: Din-Don tone
  • Consumption: standby 200mA. operating 600mA.
  • wire: 4 wires + 2 power wires + 1 video cable
  • The message LED flash if call from the 755CC
  • Dimension: 230/200/50 mm
  • Packing: 0.3 cubic ft
  • Weight: 1.5 kg
  • Alarm burglar funtion: 3 supervised zones..As specification
  • Power In: DC15~18V
  • Consumption: standby 100mA ; operating 300mA
  • wire: 4 (with CCD)
  • Resolution: B/W - 500 TV line
  • Lens: Auto
  • CCD: 1/3" CCDF1.8,Full angle 92 degree
  • Min. illumination: 0.1 Lux (w 6 pcs LED)
  • Dimension: 140/105/45mm
  • Packing: 0.3 cubic ft
  • Weight: 0.5 kg
MK755M3 Audio Handset
755CB Control Box
  • Power In: DC15~18V
  • Calling tone: Din-Don tone
  • Consumption: standby 100 mA; operating 300 mA
  • wire: 4 wires + 2 power wires
  • The message LED flash if call from the 755CC
  • Dimension: 200/100/45mm
  • Packing: 0.2 cubic ft
  • Weight: 0.4 kg
  • Power In: DC15~18V
  • Consumption: 200mA
  • Dimension: 190/110/40mm
  • Packing: 0.03 cubic ft
  • Weight: 0.5 kg
PH-P6 The Power Supply
755CSB
755DB Distributor box
  • Power In: AC110V/220V/230V
  • Power out: DC16.5-18V/2.5A
  • Dimension: 160X120X80mm
  • Packing: 0.08 cubic ft
  • Weight: 2 kg
  • Camera-system Box
  • Power In: DC15~18V
  • Consumption: 200mA
  • Dimension: 190/110/40mm
  • Packing: 0.03 cubic ft
  • Weight: 0.7 kg
  • Power In: DC15~18V
  • Consumption: 350mA
  • Dimension: 190/110/40mm
  • Packing: 0.03 cubic ft
  • Weight: 0.7 kg
