Video Doorphone for 1 Camera connect to 3 Monitors
Video Doorphone for 2 Cameras connect to 3 Monitors
Video Doorphone for 4 Cameras connect to 3 Monitors
  • Video Intercom System
  • 2-wire, non-polarity system
  • Aluminium or Plastic Camera
  • 1 Camera to 1 Monitor only
  • AC build in 90V~250V
  • Watching and hearing are available
  • View angle is adjustable
  • Dust protect of Camera
  • Water proof cover design of Camera
  • 6/12 infrared LEDs let you see clearly at night



PH-811CAL
PH-811CPL
PH-811M ( the Monitor )
  • Resolution: 500 TV lines
  • Lens: AUTO
  • CCD: 1/3" B/W CCD F1.8, Full 92°
  • Min. illumination: 0.1 lux with 12 pcs IR
  • Dimension: 240X120X60mm
  • Resolution: 500 TV lines
  • Lens: AUTO
  • CCD: /3" B/W CCD F1.8, Full 92°Min. illumination: 0.1 lux with 6 pcs IR.
  • Dimension: 130X90X40mm



  • Power In: AC In (90~250V)
  • CRT: 4" B/W flat type CRT
  • Resolution: 500 TV line
  • Power Consumption:standby-17mA/100V, 7mA/230V
  • Operating: 110mA/100V, 50mA/230V
  • Wiring: 2-wire / non-polarity
  • Dimension: 224X190X55mm
